• Channels: 4 input / 8 output

• Inputs: 4 RCA (balanced)

• Outputs: 8 RCA

• Max input level: 4Vrms (+14dBu)

• Max output level: 3.5Vrms (+13dBu)

• Input impedance: 100KΩ

• Frequency response: 10 Hz – 24 kHz (-1dB)

• THD+N: <0.01%

• Bit rate: 32-bit

• Sampling frequency: 96 kHz

• Crossover types: Linkwitz-Riley / Butterworth / Bessel (up to 48dB/oct)
• Input EQ: 15-band

• Output EQ: 8-band per channel (Q: 0.6 – 0.99)

• Time alignment: 0 – 18.95 ms

• Limiter threshold: -54 to +6 dB

• Attack time: 1 – 200 ms

• Release time: 1 – 988 ms

• Phase control: Yes

• Presets: 3

• Protection: Conformal coated PCB

• Control: Smartphone tuning

• Dimensions: 150 x 109 x 43 mm

• Full system control with independent tuning across 8 output channels

• High-resolution 32-bit / 96kHz processing for accurate signal handling

• Advanced crossover options enable proper active system design

• Time alignment and EQ allow precise staging and tonal balance

• Compact, coated design suited for harsh environments and tight installs

• Fully active front stage systems

• Motorcycle, off-road, and space-constrained installs

• OEM integration builds requiring signal correction

• Users aiming for precise tuning and system optimisation

• Installers building SQ-focused or hybrid SPL/SQ systems

DSP is what separates a good system from a properly tuned one. This gives you the control needed to actually shape the system, not just power it, especially in installs where acoustics are working against you.
