• Type: DSP amplifier (DSP + integrated amplifier)

• DSP channels: 14 processing channels

• Amplified channels: 8 (4ch Class AB + 4ch Class D)

• Power output (RMS): 4 x 25W + 4 x 50W @ 4Ω

• Power output (max): 4 x 60W + 4 x 80W @ 4Ω

• DSP chipset: ADAU1452 (ADI)

• DAC: AK4438 + PCM1754

• ADC: 2x AK5704

• Inputs: 8 high-level (12Vrms), 2 RCA (3Vrms), 1 optical (96kHz/24bit), 1 USB-OTG (192kHz/32bit)

• Outputs: 10 RCA @ 4Vrms

• High-level outputs: 8 amplified outputs

• Bluetooth: 5.0 (aptX / aptX HD / AAC / SBC)

• Frequency response: 20Hz – 40kHz

• THD+N: <0.03% (amp), <0.0017% (RCA)

• Signal-to-noise ratio: >100dB (amp), >105dB (RCA)

• Input EQ: 5-band parametric

• Output EQ: 31-band parametric per channel

• Crossover types: Butterworth / Linkwitz / Bessel

• Crossover slope: -6dB to -48dB/oct

• Time alignment: 0 – 20ms per channel

• Phase control: 0° – 360° variable

• Dynamic loudness: Independent per input source

• Control: App + controller + PC tuning

• Operating voltage: 11V – 16V

• Dimensions: 217 x 170 x 43 mm


• Combines DSP processing and amplification into one efficient, space-saving unit

• Hybrid Class AB and Class D design balances sound quality and efficiency

• OTG input allows direct high-quality digital playback from mobile devices

• 14-channel DSP enables flexible system design and expansion

• Extensive tuning control provides precise adjustment across all channels

• Entry to mid-level system upgrades needing DSP control and amplification

• OEM integration builds with limited space

• Multi-speaker systems requiring flexible routing

• Users wanting a simplified system without multiple amplifiers

• Installations prioritising efficiency and clean integration

For the right build, this simplifies the entire system. It gives you processing and usable power in one unit, which makes it ideal for clean installs where space, wiring, and complexity need to be kept under control.
