• Flat-mount design makes serious bass possible where conventional subwoofers will not fit

• Strong motor and 4-layer copper coil give the driver real authority for its depth class

• Cast basket construction helps maintain control and stability under load

• Sandwich paper cone balances output, control, and usable low-frequency extension

• Dual 2 ohm configuration gives flexible amplifier matching for compact high-output builds

• Product type: High-quality flat SPL subwoofer

• Model: GZHW 10SPL-D2 FLAT
• Series: Hydrogren Series

• Diameter: 25 cm / 10″

• Power handling: 600W RMS / 1000W max

• Impedance: 2 x 2 ohms

• Efficiency: 85 dB

• Power recommendation: 400 – 1000W RMS

• Motor: Ferrite

• Voice coil diameter: 63 mm / 2.5″

• Voice coil: 4-layer copper

• Cone: Sandwich paper

• Dust cap: PP

• Surround: Durable U-shape rubber surround

• Basket: Solid aluminum cast

• Terminals: Push terminal

• Re (series): 4.01 ohms

• Fs: 35.5 Hz

• Qms: 8.937

• Qes: 0.456

• Qts: 0.434

• Vas: 19.7 L / 0.70 cu.ft.

• Mms: 189.5 g

• Xmax: 29 mm / 1.14″ p2p

• BL: 19.3 Tm

• Mounting diameter: 238 mm / 9.37″

• Mounting depth: 103 mm / 4.06″

• Verification: Klippel® optimized

• Vented enclosure: 17L net / 0.60 cu.ft.

• Port: 1 x 70 mm / 2.76″

• Port length: 300 mm / 11.81″

• F3 frequency: 39 Hz

• Sealed enclosure (minimum): 15L net / 0.53 cu.ft.

• Qtc / F3: 0.67 / 58 Hz

• Note: sealed enclosure offers more limited low-frequency extension and reduced power handling

• Space-constrained installs needing genuine subwoofer performance

• Under-floor, side panel, and shallow enclosure applications

• Compact daily systems using serious mono amplification

• Builds where enclosure depth is limited but output still matters

• Users wanting a shallow-format sub without stepping into weak, convenience-focused designs

The standout here is the flat-mount design that still has proper motor and coil hardware behind it. A lot of shallow subs make the fitment easy but give away too much performance. This works because it is built to solve the space problem without turning into a compromise piece.
