• Product type: High-performance SPL subwoofer

• Model: GZNW 30SPL-D2

• Diameter: 30 cm / 12″

• Power handling: 3000W RMS / 6000W max

• Impedance: 2 x 2 ohms

• Efficiency: 86.3 dB

• Power recommendation: 2000 – 6000W

• Voice coil: 75 mm / 3″ CCA round wire

• Cone: Reinforced paper

• Basket: Solid aluminum cast

• Spider: 4-layer Nomex

• Dust cap: Carbon design

• Xmax: 70 mm / 2.76″

• Mounting diameter: 281 mm / 11.06″

• Mounting depth: 237 mm / 9.33″

• Resonance frequency (Fs): 41.3 Hz

• Qts: 0.54

• Vas: 25 L / 0.88 cu.ft.

• Verification: Klippel® optimized

• Massive 70 mm Xmax gives it the excursion to produce serious low-frequency output

• 3 inch CCA voice coil is built to handle real amplifier power

• Heavy-duty cast basket keeps the structure stable under extreme load

• 4-layer Nomex spider supports control and durability at high excursion

• Dual 2 ohm configuration gives flexible amplifier matching for high-power systems

• Vented enclosure: 60L net / 2.12 cu.ft.

• Port (dimensions): 10 cm / 4"

• Port length: 4.13"

• Fb / F3 (-3 dB): 47 Hz / 37 Hz

* Above-mentioned enclosure recommendations are just a few possible variations. Please note that you should find the perfect tuning, especially port length, based on your car and own taste.

• High-output daily systems using serious mono amplification

• SPL-focused builds wanting a hard-hitting 12 inch substage

• Systems chasing strong bass authority without moving to a larger 15

• Large enclosure builds designed around output and impact

• Installations with the electrical support to run real power properly


What stands out here is the combination of 70 mm Xmax and the 3 inch CCA voice coil. That gives the sub both the excursion to move serious air and the thermal capacity to handle real power, which is exactly what makes a high-output 12 actually feel convincing in the car.
